Altronix AL600ULB Power Supply Charger, Single Output, 12/24VDC 6A

Altronix AL600ULB Power Supply Charger, Single Output, 12/24VDC 6A

Original price was: $179.40.Current price is: $53.82.

Save: 70%

SKU: ID1636233 Category: Tag:

Description

Altronix AL600ULB UL Recognized power supply/charger converts a 28VAC/200VA input into a single 12VDC or 24VDC non power-limited output. It also offers a suite of features that includes AC fail supervision, battery presence, and low battery supervision.

Input Input two (2) 28VAC/100VA, 1A transformers.
Output 12VDC or 24VDC selectable output. 6A continuous supply current. Filtered and electronically regulated output. Short circuit and thermal overload protection.
Battery Backup Built-in charger for sealed lead acid or gel type batteries. Automatic switch over to stand-by battery when AC fails.
Supervision AC fail supervision (form “C” contacts). Low battery supervision (form “C” contacts). Battery presence supervision (form “C” contacts).
Temperature Operating: 0° C to 49° C (32° F to 120° F). Storage: – 20° C to 70° C ( – 4° F to 158° F). Relative Humidity 85% +/- 5%. BTU/Hr (approx.): 12VDC: 37 BTU/Hr. 24VDC: 74 BTU/Hr. System AC input VA requirement: 230VA.
Visual Indicators AC input and DC output LED indicators.
