Altronix AL1012ULACM Access Power Controller Power Supply/Charger

Description

Features:

• Eight (8) independently controlled outputs.
• Output options:
  • a) Eight (8) Fail-Safe and/or Fail-Secure power outputs;
  • b) Eight (8) form “C” 5A rated relay outputs;
  • c) Any combination of the above.
• Eight (8) auxiliary power outputs (unswitched).
• Output fuses are rated at 3.5A.
• Filtered and electronically regulated outputs.
• Supervision:
  • AC Fail
  • Battery Fail and Battery Presence.
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs.
• Alarm output relay indicates that FACP input is triggered
• Fire Alarm disconnect input options:
  • a) Normally open (NO) or normally closed (NC) dry contact input
  • b) Polarity reversal input from FACP signaling circuit.
• Built-in charger for sealed lead acid or gel type batteries.
• Instantaneous transfer to stand-by batteries.

Altronix AL1012ULACM converts a 115VAC 60Hz input into eight (8) independently controlled 12VDC non power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 10A continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs. Model AL1012ULACMCB is a PTC protected version of this unit.
