Altronix AL1002ULADA NAC Power Supply, 2 Class A or 4 Class B Outputs

Altronix AL1002ULADA NAC Power Supply, 2 Class A or 4 Class B Outputs

Original price was: $548.00.Current price is: $164.40.

Save: 70%

SKU: ID1636224 Category: Tag:

Description

Features:

  • 2-wire horn/strobe Sync mode allows audible notification appliances (horns) and visual notification appliances (strobes) to be silenced/deactivated at the same time.
  • Sync protocols include Potter/Amseco, Gentex®, System Sensor®, and CooperWheelock®.
  • Temporal Code 3, Steady Mode, Input to Output Follower Mode (maintains synchronization of notification appliances circuit).
  • Compatible with 12VDC or 24VDC fire panels.
  • Output loop supervision steered to Input 1 or Input 2.
  • Signal circuit trouble memory (helps identify intermittent loop problems).
  • Common trouble input and output for external trouble signals tie-in.
  • Ground fault detection.

AL1002ULADA is an extremely cost effective voltage regulated remote NAC Power Extender. It may be connected to any 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC) expansion (supports ADA requirements) and providing auxiliary power to support system accessories.

Subject to the use of all the optional accessories
Input Voltage 120VAC, 60Hz, 5A. Two (2) Class A or two (2) Class B inputs. Two (2) NC dry contact trigger inputs. Input Ratings (INP1 and INP2): 8-30VDC 6.5mA max from FACP. 12V 6.5mA, 24V 6.5mA from FACP.
Output Voltage: 24VDC power-limited outputs. Current: 10A max. total alarm current. 2.5A max. current per output. Two (2) outputs may be paralleled for more power on an indicating circuit. Auxiliary: 1A. Other: Thermal and short circuit protection with auto reset. Filtered and regulated outputs. Programmable Supervised Indicating Circuit Outputs: Four (4) Class B, or Two (2) Class A, or One (1) and Two (2) Class B.
Back-up Battery (not included) Type: Sealed lead acid or gel type. Failover: Upon AC loss, instantaneous.
Supervision AC Failure: Form “C” contacts. Battery: Form “C” contacts.
Indicators (LED) AC Power (Green): Input voltage is present. DC Output (Red): Powered. Logic Board (Red and Green): Output status.
Temperature Operating: 0° C to 49° C (32° F to 120° F). Storage: – 20° C to 70°C ( – 4° F to 158° F). Relative Humidity 85% +/- 5%. BTU/Hr (approx.): 31 BTU/Hr.
