ACTi A426 Camera 5MP Zoom Bullet with D/N Adaptive IR Extreme 4.4x

ACTi A426 Camera 5MP Zoom Bullet with D/N Adaptive IR Extreme 4.4x

Original price was: $2,438.00.Current price is: $731.40.

Save: 70%

SKU: ID2319913 Category: Tag:

Description

ACTi, A426, Camera 5MP Zoom Bullet with D/N, Adaptive IR, Extreme WDR, SLLS, 4.4x Zoom lens, f2.7-12mm/F1.6 (HOV:102.1°-31.5°), P-Iris, Auto Focus, H.265/H.264, 2D+3D DNR, Audio, MicroSD/ MicroSDHC/ MicroSDXC, PoE/DC12V/AC24V, IP66, DI/DO

Features:

  • ALPR
  • 5 Megapixel
  • Day & Night with Superior Low Light Sensitivity and Adaptive IR LED
  • Extreme WDR
  • Wide Angle
  • Built-in Analytics
  • Event trigger, response and notification
Device
Product Type Zoom Bullet
Maximum Resolution 5MP
Product Application ALPR
Application Environment Outdoor
Image Sensor Progressive Scan CMOS
Sensor Size 1/2.7″
Effective Pixels 2688(H) X 1944(V) (5.23 MP)
Day / Night Yes
Low Light Sensitivity Superior
Minimum Illumination Color: 0.01 lux; B/W: 0 lux (IR LED on)
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700-1100nm
IR LED Adaptive IR LED x 8 (850 nm)
IR Working Distance 40m
Electronic Shutter 1-1/10000 second (manual mode); 1-1/10000 second (auto mode)
Horizontal Resolution (TV Lines) 1600 TVL
S/N Ratio 75 dB
Number of Traffic Lanes 1
Lens
Focal Length Zoom, f2.7-12mm
Aperture F1.6
Zoom Ratio 4.4x optical zoom, 10x digital zoom
Iris P-Iris
Focus Auto focus
Lens Mount Board mount
Horizontal Viewing Angle 97.5° – 32.8°
Vertical Viewing Angle 72.1° – 24.4°
Viewing Angle Adjustment Pan: 360°, Tilt: 90°, Rotation: 360°
Video
Compression H.265 Adaptive Stream (equivalent to Zip or Smart Stream or H.265+), H.264, MJPEG
Maximum Frame Rate vs. Resolution
  • 30 fps at 2688 x 1944
  • 30 fps at 2592 x 1944
  • 30 fps at 2688 x 1512
  • 30 fps at 1920 x 1080
  • 30 fps at 1280 x 1024
  • 30 fps at 1280 x 720
  • 30 fps at 800 x 600
  • 30 fps at 720 x 480
  • 30 fps at 640 x 480
  • 30 fps at 352 x 240
  • 30 fps at 320 x 240
Multi-Streaming Simultaneous quad streams
Bit Rate Mode Constant, Variable
Wide Dynamic Range Extreme WDR (130 dB)
Image Enhancement White Balance, Brightness, Contrast, Sharpness
Digital Noise Reduction 2D + 3D DNR
Privacy Mask Yes
Text Overlay Yes
Built-in Analytics Deep Learning : Face Recognition, Face Detection, People Detection, Vehicle Detection, Object Based Motion Detection, Tampering Detection, Object Line Crossing Detection, Object Area Counting, Intrusion Detection (Forbidden Area Detection), Missing Object Detection, Unattended Object Detection, Object Loitering Detection, People Counting, People Line Crossing Detection, People Enter Area Detection, People Incorrect Direction Detection, People Loitering Detection, People Tracking, Vehicle Counting, Vehicle Line Crossing Detection, Vehicle Enter Area Detection, Vehicle Incorrect Direction Detection, Vehicle Loitering Detection, Vehicle Tracking, Stopped vehicle detection, License Plate Detection, Automatic License Plate Recognition
Image Orientation Flip, Mirror, Rotation (Corridor mode) (90°, 180°, 270°)
Audio
Audio Type 2-way, Stereo Line-in, Line-out
Audio Compression G.711, G.726, AAC, PCM
Network
Network Protocol & Service IPv4, IPv6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DDNS, NTP, RTP, RTSP, SMTP, FTP, IGMP, ICMP, ARP, UPnP, QoS, SNMP, IEEE 802.1X
Ethernet Port 1 x Ethernet (10/100/1000 Base-T), RJ-45 pigtail connector
Security IP address filtering, HTTPS encryption, Password protected user level, IEEE 802.1X network access control
Event
Event Trigger Video motion detection, External device through digital input, Sound detection, Intelligent event detection
Event Response E-mail notification with snapshots, Save video to local storage, Upload snapshot to FTP server, Activate external device through digital output
System
Watchdog Support
Integration
Unified Solution Fully compatible with ACTi software
Edge Recording Support (integration with NVR by ONVIF Profile G)
ONVIF Compliant Yes, Profile S, Profile G, Profile T, Profile M
Web Browser Microsoft Edge(IE mode), Microsoft Edge, Google Chrome, Firefox
Storage
User Database
  • User Capacity: 10,000
  • (up to 5 images per person)
Interface
Audio Interface 1/1, 3.5mm Phone Jack
Local Storage MicroSD, MicroSDHC, MicroSDXC Memory Card Slot (card not included, up to 256GB, Kingston or Sandisk only)
Digital Input/Output 2/1 (Terminal block)
Operating Button Reset Button
Installation
Vehicle Capture Speed Front-Installation: 80 km/h
General
Power Source DC 12V, AC 24V, PoE Class 0 (IEEE802.3af)
Power Consumption 16.37 W (DC), 14.30 W (AC), 12.95 W (PoE)
Weight 824g (1.82lb)
Dimensions (Ø x L): 92mm x 224.6mm (3.62″ x 8.84″)
Environmental Casing Weatherproof (IP66), Vandal proof metal casing (IK10)
Heater Yes
Starting Temperature -55°C ~ 55°C (-67°F ~ 131°F)
Operating Temperature -40°C ~ 60°C (-40°F ~ 140°F)
Operating Humidity 10% – 90% RH
Approvals CE Class A, FCC Class A, IP66, IK10 (metal casing)
Color White
Material
  • Plastic
  • Metal
Real-time Clock (RTC) Yes
